4th Dimension S.A - 3D Printing Experts - STRATASYS Origin Two

STRATASYS Origin Two

Precision Manufacturing. Redefined.

Origin® Two brings industrial 3D printing to a completely new level with unparalleled accuracy, proven repeatability, very tight tolerances, and superb smooth surface finish. Matching injection molding precision, unavailable with other resin 3D printers, it enables short production runs and on-demand manufacturing for applications that require superior quality and high part performance.

Offering the broadest range of high-performance materials in an open material system, makes it the most advanced 3D printing solution for industrial production.

Request a quote

Category: DLP / P3™ Technology

Origin Two brings the benefits of additive manufacturing for high-mix, low-volume production to high-accuracy applications.

✔️ Ideal for short production runs, accommodating both tight tolerances and large, complex parts

✔️ Open material system: select the most suitable high-performance material from the validated list, with pre-tested and optimized profile

✔️ Full flexibility: use your own material and print settings with the Open Material License

✔️ Reduce supply chain risks by bringing production in-house, especially for applications requiring accuracy, repeatability, and injection-molding quality

✔️ Enhance quality in high-precision part production by minimizing reliance on third parties and consolidating multi-component parts into single SKU

Origin Two Spec Sheet

Industries	Aerospace & Defence, Consumer Packaged Goods, Consumer Products, Education, Energy, Process & Utilities, Food & Beverage, Industrial Equipment, Life Science, Transportation & Mobility
Applications	Composite Tooling, Connectors, Fine Future Components, Jigs and Fixtures, Manufacturing, Packaging, Production Parts, Rapid Prototyping

Build Envelope	192 x 108 x 370 mm Maximum length on the diagonal — 220 mm
Achievable Accuracy	XY and Z tolerance of up to +/-50 µm for validated applications and +/- 100 µm in general
Repeatability	>95% of prints are within +/-50* µm across printers and build heads* *Between 25 µm – 200 µm layers with OpenAM™
Light Engine	5K projector with 38.5 µm pixel size and tight 2.5 standard deviation projector uniformity
Surface Finish	Surface roughness of up to 2µm Ra*
Materials	Photocurable materials, single component: • Validated materials developed by Stratasys and its material partners • Any material, via the OpenAM™ License • Changeover can be completed in under 10 min. • Long shelf lives and re-usable • Three starter materials included
Minimum Feature Size	Minimum Feature Size Material and design dependent
Wavelength	385nm
Resolution	4K light engine
Pre-Print Software	Stratasys GrabCAD Print™ or optional 3rd party solutions Touchscreen printer user interface
Regulatory Compliance	CE, UKCA, FCC, RCM, NRTL [pending]
System Size and Weight	W: 50 cm, D: 52 cm, H: 117 cm, W: 86 kg
Power Requirements	100-120 VAC, 50/60Hz, 7.1A, 1 Ph or 200-240 VAC, 50/60 Hz, 3.5 A, 1 Ph
Network Connectivity	Ethernet / Offline connectivity available with Origin Two Local
Ventilation	Ventilation Refer to photopolymer material MSDS or contact Stratasys rep for guidelines.
Operating Conditions	Operating temperature in the range of 18 °C to 25°C with humidity range of 30% to 70%
Network Security	Industry-standard end-to-end encryption
Gas Exhaust (optional)	Facility exhaust
Air Extraction Add-On	ProAero
Post-processing	Origin Cure™ - The published printer specifications for accuracy, tolerances, injection-molding like surface finish require use of Origin Cure post-processing unit.
Accessories	Including Tray Pour Jig; Lid; Pour Spout; Stand; Tray; Part Removal Jig; Scraper Jig, Printer stand, BuildHead Removal Jig (“No-drip”)
Resin Tray Capacity	2L
Resin Storage Temperature	Typically 15°C to 30°C
Transportation and Storage Temperature	Typically -20°C to 50°C
Printer Authentication	Cryptographically secure handshake
Network Security	Network Security Industry-standard end-to-end encryption

STRATASYS Origin Two

Precision Manufacturing. Redefined.
